Absorber A105 absorber Wall module
mbakustik's A105 broadband absorbers “swallow” incident sound and have been installed in countless recording studios worldwide since 1996. They are used on the wall or ceiling in control and recording rooms. They prevent direct reflections, reduce reverberation, increase spatial resolution, reduce comb filter effects and can significantly improve the stereo image.
In many other applications, these absorbers increase speech intelligibility and reduce the volume, for example in:
- Call centers, offices and lounges
- Seminar rooms and classrooms
- Daycare centers and schools
- Event and concert halls
- Restaurants, cinemas, surgeries and law firms
For small recording rooms, mbakustik's professionals recommend the A100 HR absorber variant with high-frequency reverberation.
The A105 is made to measure in mbakustik's own acoustics factory in Germany.
Made in Germany - The A105 is manufactured by hand in mbakustik's own high-quality German acoustic factory.
Dimensions
- STD 100 x 50 x 5.5 cm
- MAX1 215 x 120 x 5.5 cm
- MAX2H 107.5 x 120 x 5.5 cm
- MAX2V 215 x 60 x 5.5 cm
- Customized production possible
Technical data
- Sound absorber class A according to EN ISO 11654
- αw = 0.95
Absorber core
- Hardly flammable B1 according to DIN 4102
- free of mineral fibers, chlorinated compounds, CFCs and halogens
Mounting options
In addition to wall mounting with a perforated rear panel and hooks, mbakustik offers four practical options for mounting the A105 as a ceiling sail:
- Mounting plate + Velcro tape
- Magnet system
- Spiral hook
- Spiral hook + wire rope + carabiner
Further information on wall and ceiling mounting can be found in the data sheet and mounting sheet for the A105.
A105 vs A115
The two variants A105 and A115 differ in the lower cut-off frequency; the A115 is a true broadband absorber and can be used from around 80 Hz. This reduces modal effects such as booming or cancellations.
